Neoprene EPDM Gaskets

Alanto manufactures and supplies custom Neoprene EPDM gaskets engineered for sealing, damping and insulating in challenging conditions.
Request a Free Sample

High-Performance Gaskets for Harsh, Weather-Exposed Environments

Designed for applications where both chemical resistance and outdoor durability are essential, our gaskets combine the advantages of two premium elastomers in a single, high-performance foam.

Request a Quote
neoprene epdm gasket, rubber foam gasket, adhesive gasket UK

Made in the UK

To exact specifications and converted in-house with minimal tooling costs for prototypes or small runs.

Why Choose Neoprene EPDM Gaskets?

By blending Neoprene (known for chemical and oil resistance) with EPDM (resistant to UV, ozone and temperature extremes),

Our Gaskets offer a superior sealing solution for:

  • Outdoor enclosures and control panels.
  • HVAC duct systems and insulation interfaces.
  • Electrical switchgear.
  • Construction seals exposed to rain, sunlight or vibration.
Talk to Our Engineers

Closed-cell foam structure, flame-retardant grades, and adhesive-backed options available.

Gasket Capabilities and Technical Options

Feature Options
Thickness Range 1.5mm – 25mm (custom laminated up to 50mm)
Gasket Shape Die-cut, kiss-cut, CNC cut (flat or profiled)
Tolerances Precision cut to ±0.5mm or better
Adhesive PSA (rubber or acrylic) one or both sides
Density ~130–180 kg/m³
Flame Rating UL94 HF1, BS476 Parts 6 & 7 (available on request)
Compliance REACH, RoHS, ISO 9001

We support both one-off gaskets and high-volume repeat batches with consistent tolerances and clear labelling.

Ask an Engineer

Download Gasket Spec Sheet

Sectors and Applications

Neoprene EPDM Gaskets are relied upon across a wide range of industries:

Sector Application
Electrical & Lighting Enclosure gaskets, access panel seals
HVAC Duct connectors, vibration barrier gaskets
Construction Joint filler gaskets, facade pressure seals
Rail Hatch seals, vibration isolators
Marine Spray-resistant gaskets, engine bay seals

Ask about rail-approved and flame-retardant materials for regulated projects.

Gasket Conversion Services

Alanto’s full-service in-house conversion ensures that every gasket is produced to your exact specification.

Services include:

→ Die-cutting and oscillating knife cutting

→ Kiss cutting on carrier liner

→ Guillotine cutting for simple profiles

→ PSA lamination and roll-to-roll conversion

→ Batch packing and labelling

We also offer rapid prototyping, including CAD support and fast material sampling.

Request a Quote or Sample

We’ll help you choose the right Neoprene EPDM grade, thickness, and adhesive for your application.

    OR Upload a Technical Drawing [Max 5MB]

    Speak to a Gasket Specialist

    FAQs

    What's the difference between standard neoprene gaskets and Neoprene EPDM?

    Neoprene EPDM blends offer higher weather and UV resistance while still maintaining oil and compression performance. They are better suited for outdoor and demanding industrial environments.

    Do you offer adhesive-backed gaskets?

    Yes. Pressure-sensitive adhesive can be applied to one or both sides for easy peel-and-stick installation.

    Can I order a single gasket for a prototype?

    Absolutely. We support R&D and small batch production with fast turnaround and no tooling charges.

    Do your gaskets meet flame-retardant standards?

    We offer UL94 HF1 and BS476-compliant Neoprene EPDM for critical applications.

    Can you cut complex shapes or designs?

    Yes. Our digital cutting equipment supports intricate shapes, tight tolerances, and repeatability for batch orders.

    Precision-Sealed, Weather-Resistant and Built to Perform

    Whether you’re sealing against vibration, water, heat or pressure,
    Alanto’s Neoprene EPDM gaskets deliver consistent performance – with expert support, short lead times and guaranteed quality.
